-> JUSCAR F6 4K dash cam
BACK
Specifications
Installation
Features
FAQ
UserManual
F6
Brand:
JUSCAR
| Official Guide Price:
168.00
USD
JUSCAR F6 【WiFi】【Front and Rear】【UHD 4K+1080P】 【GPS】【ADAS】【STARVISION2 HDR Night Vision】【Touch Screen】 【24H Parking Mode】 【Support 512GB Max】
Product Parameters
Charging Method
Car Charger
Microphone/Speaker
Built-In
Max Supported Memory
256G
Language
English
Resolution
2160P
Video Frame Rate
25fps
Screen Size
10.99"
Lens Aperture
1.4
Lens Angle
170°
Shell Material
Precision Plastic
Shell Color
Black
Photo Pixel
8 Megapixels
Photo Format
JPG
Number of Lenses
Dual Lens
Installation Steps
Product Features
In-Car WiFi
Emergency Recording
Reversing Camera View
No-Light Night Vision
Emergency Photo Capture
Ultra-Wide Angle of View
Time-Lapse Recording
WiFi Connectivity
Smartphone Connectivity App
Loop Recording
Collision Detection
Parking Monitoring
Front and Rear
Touch Control
Button Desc
Video Lock Icon :In recording mode, a short press locks the video to protect it from being automatically overwritten in loop recording.
Mode Icon :In standby mode, a short press of the M button switches to the function selection screen, while a long press of the M button turns Wi-Fi on or off.
Reset Icon :To restore factory settings, press and hold with a pin for 5 seconds.
Menu Icon :In standby or recording mode, a short press directly enters playback mode, and pressing again switches video options. Press and hold for 3 seconds to return to the dash cam's main screen.
Down Icon :In menu mode and file browsing mode, the button functions as a down-page key. In standby and recording modes, a short press allows you to take snapshots.
Up Icon :In menu mode and file browsing mode, the button functions as an up-page key. In standby and video modes, a short press switches the display between front and rear cameras.
Recording Icon :The dashcam is recording
Audio Recording Icon :The dashcam is recording audio
GPS Port :GPS Module Interface
TF Card Slot :TF card slot, please insert in the correct direction
AV Icon :Rear Camera Interface
Charging USB Port :5V DC power supply interface
Power Button :In standby or recording mode, press and hold to power on/off; short press to turn the screen backlight on/off.
Notice Question
FAQ
JUSCAR F6.Manual Click to View
Download PDF
